Power

Engine Type: Single cylinder,4-stroke,air-cooling, camshaft downward, with balance shaft

Displacement: 56.8 ml

Bore x Stroke: Ф44×37.4mm

Max Power: 1.6（1±10%）/7000（1±5%）kw/r/min

Max Torque: 2.7(1±10%）/4000（1±5%）N.m/r/min

Compression Ratio: 8.5:1

Shift Type: Automatic clutch, One gear

Start Type: Electric Start

Ignition :CDI

Drive Train: #420 Chain, FT: 14T/RR: 39T Sprocket

Performance

Front Fork: Φ39*Φ42-550mm Inverted Hydraulic Forks, 100mm Travel

Rear Shock: 10.5*240mm None-Adjustable Shock, 50mm Travel

Front Wheel: Aluminum Rim, FT: 1.40 x 12

Rear Wheel: Aluminum Rim, RR: 1.40x 10

Front Tires: 2.75-12

Rear Tires: 3.00-10

Front Brake: Single Piston Caliper, 190mm Disc

Rear Brake: Single Piston Caliper, 190mm Disc

Details

Frame: Cradle Type Steel Tube Frame

Swing-Arm: Tube High Strength Steel Swingarm

Handle Bar: Aluminum #6061

Overall Size: 1520*650*840mm

Packing Size: 1205x335x615mm

Wheel Base: 1010 mm

Seat Height: 620 mm

Ground Clearance: 210 mm

Fuel Capacity: 2.2L /0.58gal.

N.W: 42.5KG

G.W: 56.5KG
