Power

Engine Type: 110CC, Single Cylinder, 4-Stroke, Air Cooled

Displacement: 107 ml

Bore x Stroke: Ф52.4×49.5mm

Max Power: 5.0/8000±500 kw/r/min

Max Torque: 7.5/5500±500 N.m/r/min

Compression Ratio: 9.0:1

Shift Type: Automatic clutch, One gear

Start Type: Electric Start

Ignition : CDI

Drive Train: #420 Chain, FT: 14T/RR: 39T Sprocket

Performance

Front Fork: Φ39*Φ42-590mm Inverted Hydraulic Forks, 100mm Travel

Rear Shock: 10*270mm None-Adjustable Shock, 50mm Travel

Front Wheel: Aluminum Rim, FT: 1.40 x 12

Rear Wheel: Aluminum Rim, RR: 1.60 x 10

Front Tires: 2.75-12

Rear Tires: 3.00-10

Front Brake: Single Piston Caliper, 190mm Disc

Rear Brake: Single Piston Caliper, 190mm Disc

Details

Frame: Cradle Type Steel Tube Frame

Swing-Arm: Tube High Strength Steel Swingarm

Handle Bar: Aluminum #6061

Overall Size:1550*710*1030mm

Packing Size: 1405x380x675mm

Wheel Base: 1010 mm

Seat Height: 580 mm

Ground Clearance: 170 mm

Fuel Capacity: 3.5L / 0.92 Gal.

N.W: 52.5KG

G.W: 59.5KG
